aluminum screw jacks
Type
Worm Gear Screw Jack Reducer
Transport Package
Standard Exporting Plywood Cases
Specification
JTC, JTW Worm Gear Screw Jacks
Trademark
JACTON
Origin
Made in China
HS Code
8428909090
Production Capacity
6666PCS Per Month
Product Description
We are professional best worm gear jack pitch 6, aluminum screw jacks, 90 degree screw type gearbox manufacturers and suppliers from China. All Jacton worm gear jack pitch 6, aluminum screw jacks, 90 degree screw type gearbox are used to pushing, pulling, apply pressure as linear actuators, and offer positive mechanical action, precise positioning, and uniform lifting speeds.
JTC Series Cubic Screw Jack
Jacton JTC series cubic screw jack features: a compact and versatile cubic housing, with high reliability and performance are guaranteed with the same precision worm and worm gear set and acme screw. Load capacity from 2.5 kN to 500 kN as standard. Translating screw and rotating screw configurations, anti-rotation (keyed) design option. Each model has two worm gear ratios and single screw lead as standard, customized double screw leads. Worm shaft is rotated by a handwheel (hand wheel manual screw jack) or by an electric motor (electric screw jack). Can be connected together in screw jack lift systems so that multiple units can be operated and controlled together.
| 2.5 kN Cubic Mini Screw Jack (0.25T) 1. Maximum static load capacity 2.5kN 2. Lifting screw Tr 14x4 3. Gear ratios 5:1, 20:1 4. Custom made travel length 5. Translating, rotating screw design 6. Multiple mini screw jack systems 7. Hand wheel operated, motor driven | 5 kN Cubic Small Screw Jack (0.5T) 1. Maximum static load capacity 5kN 2. Lifting screw Tr 18x4 3. Gear ratios 5:1, 20:1 4. Custom made travel length 5. Translating, rotating screw design 6. Anti-rotation keyed screw design 7. Multiple small screw jack systems 8. Hand wheel operated, motor driven | 10 kN Cubic Screw Jack (1T) 1. Maximum static load capacity 10kN 2. Lifting screw Tr 20x4 3. Gear ratios 5:1, 20:1 4. Custom made travel length 5. Translating, rotating screw design 6. Anti-rotation keyed screw design 7. Multiple small screw jack systems 8. Hand wheel operated, motor driven |
| 25 kN Cubic Screw Jack (2.5T) 1. Maximum static load capacity 25kN 2. Lifting screw Tr 30x6 3. Gear ratios 6:1, 24:1 4. Custom made travel length 5. Translating, rotating screw design 6. Anti-rotation keyed screw design 6. Multiple units screw jack systems 7. Hand wheel operated, motor driven | 50 kN Cubic Screw Jack (5T) 1. Maximum static load capacity 50kN 2. Lifting screw Tr 40x7 3. Gear ratios 7:1, 28:1 4. Custom made travel length 5. Translating, rotating screw design 6. Anti-rotation keyed screw design 6. Multiple units screw jack systems 7. Hand wheel operated, motor driven | 100 kN Cubic Screw Jack (10T) 1. Maximum static load capacity 100kN 2. Lifting screw Tr 55x9 3. Gear ratios 9:1, 36:1 4. Custom made travel length 5. Translating, rotating screw design 6. Anti-rotation keyed screw design 7. Multiple small screw jack systems 8. Hand wheel operated, motor driven |
| 150 kN Cubic Screw Jack (15T) 1. Maximum static load capacity 150kN 2. Lifting screw Tr 60x9 3. Gear ratios 9:1, 36:1 4. Custom made travel length 5. Translating, rotating screw design 6. Anti-rotation keyed screw design 7. Multiple small screw jack systems 8. Hand wheel operated, motor driven | 200 kN Cubic Screw Jack (20T) 1. Maximum static load capacity 200kN 2. Lifting screw Tr 70x10 3. Gear ratios 10:1, 40:1 4. Custom made travel length 5. Translating, rotating screw design 6. Anti-rotation keyed screw design 7. Multiple small screw jack systems 8. Hand wheel operated, motor driven | 250 kN Cubic Screw Jack (25T) 1. Maximum static load capacity 250kN 2. Lifting screw Tr 80x10 3. Gear ratios 10:1, 40:1 4. Custom made travel length 5. Translating, rotating screw design 6. Anti-rotation keyed screw design 7. Multiple small screw jack systems 8. Hand wheel operated, motor driven |
| 350 kN Cubic Screw Jack (35T) 1. Maximum static load capacity 350kN 2. Lifting screw Tr 100x10 3. Gear ratios 10:1, 40:1 4. Custom made travel length 5. Translating, rotating screw design 6. Anti-rotation keyed screw design 7. Multiple small screw jack systems 8. Hand wheel operated, motor driven | 500 kN Cubic Screw Jack (50T) 1. Maximum static load capacity 500kN 2. Lifting screw Tr 120x14 3. Gear ratios 14:1, 56:1 4. Custom made travel length 5. Translating, rotating screw design 6. Anti-rotation keyed screw design 7. Multiple small screw jack systems 8. Hand wheel operated, motor driven | |
Dimension Drawing
